VOCs（挥发性有机化合物）回收装置是针对工业生产过程中排放的有机废气进行收集、净化和资源化利用的环保装备，广泛应用于石油化工、化学工业、医药化工、包装印刷、锂电池生产等行业。与单纯的VOCs销毁技术（如燃烧）不同，VOCs回收装置的核心价值在于将废气中的有机组分以液态或高浓度形式回收再利用，实现环境保护与资源节约的统一。

VOCs (volatile organic compounds) recovery equipment is an environmental protection device that collects, purifies, and utilizes organic waste gases emitted during industrial production processes. It is widely used in industries such as petrochemicals, chemical industry, pharmaceutical and chemical industry, packaging and printing, and lithium battery production. Unlike simple VOCs destruction technologies such as combustion, the core value of VOCs recovery devices is to recycle and reuse organic components in liquid or high concentration form from exhaust gas, achieving the unity of environmental protection and resource conservation.

VOCs回收装置的核心技术主要包括吸附法、冷凝法、膜分离法及其组合工艺。吸附法是利用活性炭（颗粒炭、活性炭纤维、蜂窝状活性炭）、分子筛等吸附材料的多孔结构，将VOCs分子吸附在材料表面。吸附饱和后，通过热脱附、真空脱附或蒸汽脱附实现吸附剂再生和VOCs回收。吸附法适用于低浓度、大风量的VOCs废气处理。冷凝法通过降低温度使VOCs从气相转变为液相，适用于高浓度、小风量的废气处理。膜分离法利用不同气体分子在膜材料中渗透速率不同的原理，实现VOCs与空气的选择性分离。膜技术常与冷凝、吸收、活性炭吸附等技术耦合使用，实现VOCs的高效治理与资源化利用。

The core technologies of VOCs recovery devices mainly include adsorption, condensation, membrane separation, and their combined processes. The adsorption method utilizes the porous structure of adsorption materials such as activated carbon (granular carbon, activated carbon fibers, honeycomb activated carbon) and molecular sieves to adsorb VOCs molecules onto the surface of the material. After adsorption saturation, adsorbent regeneration and VOCs recovery are achieved through thermal desorption, vacuum desorption, or steam desorption. The adsorption method is suitable for the treatment of VOCs waste gas with low concentration and high air volume. The condensation method converts VOCs from the gas phase to the liquid phase by lowering the temperature, making it suitable for the treatment of high concentration and low air volume exhaust gases. The membrane separation method utilizes the principle that different gas molecules have different permeation rates in membrane materials to achieve selective separation of VOCs from air. Membrane technology is often coupled with condensation, absorption, activated carbon adsorption and other technologies to achieve efficient treatment and resource utilization of VOCs.

在实际工程中，单一技术往往难以满足复杂工况的处理要求，组合工艺成为行业主流。常见的组合路线包括：冷凝（吸收）+膜分离+活性炭吸附，适用于超高浓度油气回收；活性炭吸附+氮气脱附冷凝回收，适用于中小风量高浓度废气；活性碳纤维吸附回收+沸石转轮吸附浓缩两级净化，适用于包装印刷、锂电池生产等行业。以陕煤集团某公司煤焦油加氢项目为例，其采用的“压缩低温循环吸收+膜分离+活性炭吸脱附耦合工艺”已稳定运行超过一年。山东鲁抗医药股份有限公司的头孢车间膜法二氯甲烷尾气回收项目，处理规模达1000m?/h，是医药行业VOCs回收的典型应用。

In practical engineering, a single technology often fails to meet the processing requirements of complex working conditions, and combination processes have become the mainstream in the industry. Common combination routes include condensation (absorption)+membrane separation+activated carbon adsorption, suitable for ultra-high concentration oil and gas recovery; Activated carbon adsorption+nitrogen desorption condensation recovery, suitable for high concentration exhaust gas with small and medium air volume; Activated carbon fiber adsorption recovery+zeolite rotary adsorption concentration two-stage purification, suitable for industries such as packaging printing and lithium battery production. Taking the coal tar hydrogenation project of a certain company in Shaanxi Coal Group as an example, the "compressed low-temperature cycle absorption+membrane separation+activated carbon adsorption desorption coupling process" adopted has been operating stably for more than a year. The membrane based dichloromethane tail gas recovery project in the cephalosporin workshop of Shandong LuKang Pharmaceutical Co., Ltd. has a processing capacity of 1000m ³/h and is a typical application of VOCs recovery in the pharmaceutical industry.
